Diode Circuit and Power Supply
Item Code : SJ252
Principle and Working:
In half-wave rectification, either the positive or negative half of the AC waveform is allowed to pass, while the other half is blocked. A full-wave rectifier converts the entire input waveform into one of constant polarity (either positive or negative) at its output. A filter capacitor is an energy storage device installed at both ends of the rectifier circuit. It helps to reduce the ripple in the AC signal and improves the efficiency and smoothness of the resulting DC output. A regulated power supply is an electronic circuit designed to produce a constant DC voltage or power output. It maintains consistent output regardless of variations in load current, input voltage, or temperature. An unregulated power supply, on the other hand, provides a fixed output based on the input and load conditions. Even small variations in the input voltage can directly affect the output voltage.
- Plug-in Modules to design electronic circuit.
- ‘Do It Yourself Approach’ provides better learning.
- The plug-in modules are designed in transparent housing for clear visibility of the components.
- The symbols and name printed on transparent cover for easy identification of components.
- Very convenient & easy to use 4mm sockets and Plugs to make circuit.
- Economical & Flexible method of performing all experiment on one circuit board.
- Safety as per European standard.
- To study half wave and full wave rectifier.
- To study full wave (bridge) rectifier.
- To study capacitor filter effect in power supply
- To study unregulated and regulated power supply.
- 2 Pin Module: Transparent Cover, Symbol and Value printed on Transparent cover, 4 mm plugs (2 nos.), Electronics Component mounted on PCB.
- 4 Pin Module: Transparent Cover, Symbol and Value printed on Transparent cover, 4 mm plugs (4 nos.), Electronics Component mounted on PCB.
- Plug in Safety Leads: 4mm pin dia with safety mould, length 100, 50 and 25 mm, Colour: Red, Black and Yellow.
- Plug in Circuit Board: Size: H: 50 mm, L: 302 mm, W: 245 mm, Socket Size: 4 mm, 24 quadrant, 4 holes per quadrant.
- Transformer Module: Output Range 15-0-15 V AC, Output Socket 4 mm Safety Socket (Yellow and Black), Input 230V AC.
| S.No. | Item Name | SJ252 |
| 1 | Bridge rectifier module | 1 |
| 2 | Capacitor module (10 µF) | 1 |
| 3 | Capacitor module (100 µF) | 1 |
| 4 | Capacitor module (1000 µF) | 1 |
| 5 | Digital multimeter | 2 |
| 6 | Diode module (1N 4007) | 2 |
| 7 | Flexible plug in lead 25cm (black) | 4 |
| 8 | Flexible plug in lead 25cm (red) | 4 |
| 9 | Flexible plug in lead 50cm (black) | 2 |
| 10 | Flexible plug in lead 50cm (red) | 2 |
| 11 | Flexible plug in lead 50cm (yellow) | 2 |
| 12 | LED module (red) | 1 |
| 13 | Plug in circuit board | 1 |
| 14 | Regulator module (5V) | 1 |
| 15 | Resistance module (1 kΩ) | 1 |
| 16 | Resistance module (330 Ω) | 1 |
| 17 | Resistor module (27 kΩ) | 2 |
| 18 | Transformer module (9-0-9V) | 1 |
